TP-Link 8Port 10/100MBPS Desktop Switch
Highlights:
- 8 x RJ45 Ports, Auto MDI / MDIX
- 8K MAC Address Table
- 9K Jumbo frame
- 16Gbps Switching Capacity
- Saves the Power up to 80%
- IEEE 802.3x Flow Control
- Plug and Play
Â
Overviews:
What This Product Does
Increase the speed of your computer network with the TL-SG1008D Eight-Port Unmanaged Gigabit Desktop Switch from TP-LINK. Suitable for the home, the office, a workgroup, or a creative production environment, this device can improve your network server and backbone connections to speeds of up to 1,000 Mbps. This ensures that graphics, CGI, CAD, or multimedia files and other applications with bandwidth-intensive files are transferred across the network almost instantly. Diagnostic LED indicators help you quickly detect and respond to network problems, while power-saving features make the device environmentally friendly.
-
Faster Network Response Times
The non-blocking switching architecture adopted in the Eight-Port Unmanaged Gigabit Desktop Switch greatly improves network response times and significantly speeds up the traffic between subnets by forwarding and filtering packets at full wire speed for maximum throughput. -
Diagnostic LED Indicators
The TL-SG1008D features diagnostic LEDs that display link status and activity, enabling you to quickly detect and correct problems on the network. -
Universal System Compatibility
The TL-SG1008D is compatible with all 10, 100, and 1,000 Mbps Ethernet devices, allowing you to protect your existing investments while migrating to a faster network. -
Power-Saving Features
With green Ethernet technology and power-saving features, the TL-SG1008D help make your network environmentally friendly without compromising performance. The switch automatically powers down the ports that are idle and budgets power output for different Ethernet cable lengths.
Â
Features:
- The built-in energy-efficient technology saves power of up to Up to 80% when compared to conventional TP-Link switches
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
- Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
- Switching capacity of 16Gbps
- 15k Jumbo frame improves performance of large data transfers
- Store and forward switching scheme
- Auto-MDI/MDIX eliminates the need for crossover cables
- Supports MAC address auto-learning and auto-aging
- Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps, and 1000Mbps hardware
- Plug and Play design simplifies installation
- The switch features a quiet, fan-less design so that it doesn't disturb anyone working nearby
Â
Specifications
| Performance | |
|---|---|
| Standards | IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX) IEEE 802.3x IEEE802.3ab |
| Protocols | CSMA/CD, TCP/IP |
| Ports | 8x RJ-45 for 10/100/1000Mbps Ethernet ports with Auto MDI/MDIX |
| MAC Address Table Size | 8K |
| Frame Size | Jumbo Frame: 15K |
| Transmission | Method: Store and Forward |
| Switching Capacity | 16Gbps |
| Data Transfer Speed | Half Duplex: 10Mbps 100Mbps 1000Mbps Full Duplex: 20Mbps 200Mbps 2000Mbps |
| Advanced Features | MAC Address Auto-Learning and Auto-aging IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode |
| LED | Power, Link/Act for all ports |
| General | |
|---|---|
| System Requirements | Windows 2000/XP/Vista/7 Linux MAC OS |
| Certifications | FCC, CE, RoHs |
| Environmental Requirements | Operating Temperature: 32° to 104°F / 0° to 40°C Non-Operating Temperature: -40° to 158°F / -40° to 70°C Operating Humidity: 0% to 90% (non-condensing) Storage Humidity: 5% to 90% (Non-condensing) |
| Power Requirements | External Power Adapter: 100 to 240VAC, 50/60Hz |
| Dimensions | 6.5 x 4.3 x 1.1" / 16.5 x 10.8 x 2.8cm |
UPC Code
0845973020262
